Supported Wrappers (File Formats)
- MPG, M2P, AVI, F4V, MXF (OP1a), MOV, MP4, TS, WMV, WAV, M4A, P2, AAF
Supported Video Codecs
- Standard/Broadcast: MPEG-2, DV, DVCPRO, DVCPRO50, DVCPROHD, IMX, XDCAM (HD/EX), AVC-Intra, XAVC
- Professional/Editing: Apple ProRes (server only), Avid DNxHD/DNxHR, VC-1, JFIF
- H.264/HEVC: H.264/AVC, H.265/HEVC (with GPU hardware acceleration support)
- Uncompressed: YUV and RGB formats (e.g., YUY2, UYVY, RGB24, RGB32, NV12, YV12, V210)
- Other: JPEG2000 (GPU-based)
Supported Audio Codecs
- PCM (WAV), AAC, WMA, MPEG Audio (Layers 1, 2, and 3), AC3 (ATSC A/52)
Inputs & Platforms
- SDI via Blackmagic Design, AJA, Bluefish444, Matrox, Deltacast
- NDI and IP streams (UDP, RTP, RTMP, SRT, RTSP)
- DirectShow-compatible devices
- Native 64-bit Windows application
